High Purity Xenon difluoride Gas (XeF2) Fluorocarbon Gases

Product Name:

Xenon difluoride (XeF2)

CAS:

13709-61-0

UN No.:

3087

Package Volume:

customized

Cylinder :

customized

Valve:

customized



Product

Grade

Xenon difluoride (XeF2) 3N

≥ 99.999%

    Why hesitate ? Inquiry us Now !

    Contact us

    Characteristics

    Appearance  white , solid crystals , pungent/ozone like
    Density  4.32kg/L
    Melting Point  128.6 °C
    Boiling Point  114°C
    Vapor Pressure  0.5Kpa at 25 °C
    Stablility to air  react with moisture in air to form HF .
    Stablility to water  25 g/L at 0 °C and hydrolyses to form HF
    Solubility  Soluble in solvents such as BrF5, BrF3, IF5, anhydrous HF, and CH3CN, without reduction or oxidation . Solubility in HF is high , at 167g per 100g HF at 29.95°C.

    product description

    Xenon difluoride (XeF2) is a colorless solid with a molecular weight of 169.30, it is easy to sublimate at room temperature and form transparent crystals. Xenon difluoride decomposes in neutral or alkaline solution, but it is stable in acidic solution and has a pungent odor in aqueous solutions. Vapor of xenon difluoride is colorless and has a disgusting stench. In the electronic industry, XeF2 is often used as etching gas of silicon, chemical reaction of XeF2 and silicon is spontaneous reaction, corrosion process of XeF2 to silicon has high selectivity, in the corrosion process of XeF2 to silicon, XeF2 gets to the surface of silicon substrate through free gas diffusion, and react with the outermost silicon atoms to generate gaseous Xe and gaseous SiF4, so as to realize corrosion of silicon.
    Here is a detailed overview of the physical properties of difluorine xenon:

    Uses
    XeF2 is used in the synthesis of other xenon fluorides, which are important in the study of fluorine chemistry and in industrial applications.
    It is also used in the electronics industry for etching processes.

    Safety

    * XeF2 reacts with moisture in air to form HF.
    * XeF2 has a strong ozone like odour.
    * XeF2 is packaged in a dry nitrogen atmosphere.
    * Transfer of XeF2 from PTFE bottles should be carried out in a dry nitrogen glove box or alternatively under a fume hood.
    * PTFE bottles are sealed at atmospheric pressure and are packaged in a sealed metal can together  with a safety absorbent.
    * Cylinders are pressurized to 100 kPa (gauge) with helium and helium leak tested.
    * XeF2 is soluble in water (25 g/L at 0 C) and hydrolyses to form HF.
